Geometers study shapes and how they transform into one other. Musicians create shapes and transform them. We illustrate with some examples that are interesting to both geometers and musicians.

The same lecture is given at both 1pm and 6pm.

This is a part of the series, Maths and Music, which explores a range of connections between these two related disciplines.
The other lectures include:

        Why Are Pianos Out of Tune? by Professor Robin Wilson
        Composing With Numbers by Professor Jonathan Cross



Download Transcript




The Geometry of Music



Professor Wilfrid Hodges



1. Music takes place in a two-dimensional space, where the dimensions are time and pitch.

Usually we write time from left to right, and higher pitch is higher on the page. (So time is on

the x axis and pitch on the y axis.) Conventional western music uses only certain pitches and

rhythms.

Edward Elgar, 'Enigma Variations: xi, GRS', EMI 1983.

George Gershwin, 'Rhapsody in Blue', with Paul Whiteman, Gemm 1991.

Fairuz, 'Ya mersal el marassil', Chahine 1993.

2. Since the time of Felix Klein (1849-1925), geometers have classified spaces and their

contents by applying transformations and seeing what stays fixes and what moves. We

multiply transformations S and T by doing S first and then T; we invert T by doing T

backwards. A transformation group consists of a nonempty set of transformations of a space,

closed under multiplication and inverse. For musical space one of the most important groups

is the Klein Four-group with multiplication table

3. The transformation Mh moves points in time, as if they were reflected in a mirror placed

vertically. Applying Mh to a piece of music runs it backwards in time. Some pieces are the

same forwards as backwards, so Mh leaves them unchanged; we say Mh is a symmetry of

these pieces.

Georg Handel, 'Messiah: Hallelujah Chorus', Naxos 1992.

4. The transformation Mv turns pitches upside down, as if in a mirror laid horizontally. It's

not always obvious when one piece is the same as another but upside down.

Nicol`o Paganini, 'Capriccio 24 for Violin', DG 1978.

Sergei Rachmaninov, 'Rhapsody on a theme of Paganini: Variation 18', Vox Box 1991.

5. Rotation R turns a thing around by 180 degrees, so that it's upside down and faces

backwards. Multiplying transformations, R equals Mh ×Mv. Rimsky-Korsakov uses a theme

with symmetry R (but not Mh or Mv) for a signal that can be sent two ways.

Nikolai Rimsky-Korsakov, 'The golden cockerel', DCA 1991.

6. Pieces whose group of symmetries is the entire Klein Four-group are very hard to find. It

seems most composers avoid them.

John Tavener, 'The Lamb', Naxos 2000.

7. The only other groups that transform a musical theme within a bounded area of musical

space involve rotations through other angles, and these don't seem to be musically

significant. So to go beyond the Klein Four-group we need transformations of infinite order;

these generate groups that take a theme arbitrarily far away from its original position. The

simplest example is a translation Th moving everything through a fixed distance in time.

Doing Th once gives a repeat.

8. Doing Th once and then twice gives the same theme three times in a row. Like '• • • ', this

suggests an infinite repetition, or something that sounds over and over again like a church

bell.

Benjamin Britten, 'Peter Grimes'.

Arvo P¨art, 'Cantus in memoriam Benjamin Britten', EMI Classics for Pleasure 2002.

9. Multiplying Th by Mv gives an upside down repetition (called a glide reflection).

Judith Weir, 'King Harald's Saga'.

10. Horizontal dilation Dh stretches the time in some fixed ratio r. (If r > 1 it slows down the

music, if 0 < r < 1 it speeds it up.) An example of Dh combined with a translation is at a high

point of Brahms' Requiem, where he chose his own words 'You are sad now, but I will see

you again; I will comfort you', apparently in memory of his mother. The theme on 'I will see

you again' is repeated lower and slower, as if by Brahms himself responding to his mother.

Johannes Brahms, 'Ein Deutsches Requiem: Ihr habt nun Traurichkeit', EMI Classics 1993.

11. Multiple applications of Dh together with translations generate two striking pieces of

music. Nancarrow takes the ratio very close to 1, so the themes get closer towards the middle

of the piece, raising the tension continuously, and then drift apart. Finer makes the separate

voices repeat too, and fixes the ratios so that the voices come into alignment exactly once

every thousand years.

Conlon Nancarrow, 'Studies for Player Piano 36', Wergo 1990.

Jem Finer, http://longplayer.org

12. We started by classifying the musical themes within a given framework of pitches and

rhythms (a subspace of the full musical space). By the end we were classifying the

frameworks too. Since around 1900, many western composers have built their own

frameworks instead of accepting one given by the style of the time. As an example of

choosing a framework, I give two new scales that contain exactly the same intervals the same

number of times, but are not either the same scale or inversions of each other. (This last is

work in progress, joint with Patrick Ozzard-Low.)


J. Fauvel. R. Flood and R. Wilson eds., Music and Mathematics: From Pythagoras to

             Fractals, Oxford University Press 2003.


L. Harkleroad, The Math behind the Music, Cambridge University Press 2006.




D. Lewin, Generalized Musical Intervals and Transformations, Oxford University Press

   2007. (For the serious scholar. Full of musical insights, but I think it makes the mathematics needlessly heavy.)
